Well Cap Assembly

The new 2" Locking Well Caps are designed for both standard and Direct Read Cable deployment options.

The well cap has a convenient eyelet for suspending Leveloggers using wireline or Kevlar cord. The Well Cap insert has two openings to accommodate Direct Read Cables for both a Levelogger and Barologger. Adaptors are available to fit 4" wells.

The cap is vented to equalize atmospheric pressure in the well. It slips over the casing, and the cap can be secured using a lock with a 3/8" (9.5 mm) shackle diameter.

solinst levelogger levelogger edge locking well caps levelogger well caps levelogger edge well caps installing leveloggers levelogger well installation caps image

Levelogger 2" Locking Well Cap Installations
(see Well Caps datasheet for more details)
