Portable Data Transfer & Telemetry

DataGrabber

solinst datagrabber data transfer unit for leveloggers

The DataGrabber is a field-ready data transfer device that allows you to copy data from a Levelogger, onto a USB flash drive key.

The DataGrabber is compact and very easy to transport. It connects to the top end of a Levelogger’s Direct Read Cable, or an Adaptor is available to allow direct connection to a Levelogger.

One push-button is used to download all of the data in a Levelogger’s memory to a USB device plugged into the DataGrabber. A convenient LED light indicates the operation of the DataGrabber. The data in the Levelogger memory is not erased, and logging is not interrupted if the Levelogger is still running. The DataGrabber uses its own replaceable 9V battery.





levelsender telemetry systems for levelogger

solinst levelsender telemetry systems for levelogger schematic in well image

LevelSender Telemetry

The LevelSender is a simple, low cost telemetry system designed to send data from Leveloggers in the field, to your smart device and PC database via cellular communication.

Initial set up is done through a user-friendly software wizard at the Home Station. There is twoway communication between the LevelSender and Home Station, allowing remote updates.

Each LevelSender device has a single port to connect one Levelogger with an optional splitter that allows the connection of a Barologger.

LevelSender stations are compact in design, which allows them to be discreetly installed inside a 2" (50 mm) well (see Model 9500 LevelSender data sheet).



solinst sts telemetry system for leveloggers

STS Telemetry

The STS Telemetry System provides an efficient method to send Levelogger data from the field to your desktop. Cellular communication options give the flexibility to suit any project. STS Systems are designed to save costs by enabling the selfmanagement of data. Alarm notification, remote firmware upgrades and diagnostic reporting make system maintenance simple (see Model 9100 STS Solinst Telemetry System Data Sheet).



solinst rrl remote radio link telemetry system for leveloggers

RRL Telemetry

The RRL Remote Radio Link is ideal for short range applications up to 20 miles or 30 km; distances can be increased by using radios as relay stations. Ideal for creating closed-loop monitoring networks using Leveloggers (see Model 9100/9200 Telemetry Systems data sheet).
